Laser tube metal cutting machine double chuck for steel for sale in Italy can process a variety of metal pipes and tubes, including round tubes, square tubes and special-shaped tubes or pipes. It can do hole cutting, beveling, grooving, vertical cutting, carving on metal tubes with high precision and efficiency. This metal tube laser cutter is widely used in automobile exhaust pipes, water pipes, oil pipes, fitness equipment, medical bed, bicycle frames, electric bicycle frames, baby carriages, kitchen storage racks, kitchenware, etc.
Laser tube metal cutting machine double chuck for steel for sale in Italy Advantages
1. Special design for pipes.
2. The laser output power is adjustable from 500W to 4000W.
3. It is easy to operate and can increase the cutting volume and cutting efficiency.
4. Widely used in sports equipment, various pipes, water pipes, oil pipelines and other industries.
5. The machine adopts the world-class Raycus/Max laser source, and the cutting edge is smooth without any burrs.
6. It is made of aerospace aluminum alloy gantry, with high processing precision, good toughness and fast processing speed.
Laser tube metal cutting machine double chuck for steel for sale in Italy video
Laser tube metal cutting machine double chuck for steel for sale in Italy SPECIFICATIONS
Model | DXTECH-TK6220/TK9220 | DXTECH-TK62406220/TK9240 | DXTECH-TK6300/TK9300 | DXTECH-TK6360/TK9360 |
Max. tube length | 6.5/9.2m | 6.5/9.2m | 6.5/9.2m | 6.5/9.2m |
Tube shape | Round/square/rectangular | Round/square/rectangular | Round/square/rectangular | Round/square/rectangular |
Max. tube weight | 300kg 16kg/m | 350kg 55kg/m | 600kg 30kg/m | 1000kg 83kg/m |
Positioning accuracy | ±0.03mm | ±0.03mm | ±0.03mm | ±0.03mm |
Repositioning accuracy | ±0.02mm | ±0.02mm | ±0.02mm | ±0.02mm |
Chuck | Two pneumatic chucks | Two pneumatic chucks | Two pneumatic chucks | Two pneumatic chucks |
Max. chuck rotating speed | 130r/min | 130r/min | 130r/min | 130r/min |
Laser power | 1kW – 4kW | 1kW – 4kW | 1kW – 4kW | 1kW – 4kW |
Laser | Multiple options | Multiple options | Multiple options | Multiple options |
Clamping range | Φ20-Φ220mm □20 – □150mm |
Φ20-Φ240mm □20 – □170mm |
Φ10-Φ300mm □20 – □210mm |
Φ20-Φ360mm □20 – □250mm |
DXTECH service
We warmly welcome domestic and overseas customers to visit our factories and offices and talk about business in person. We now have one workshop with an area of 45,000㎡ in Jinan and one factory with an area of 30,000㎡ under construction in Taian, Shandong Province.
Your salesperson and factory technicians will together take care of all your after-sales issues from the moment you received the laser machine.
We provide free online training and techinical support. Besides, we can also go to your place to settle down the installation, debugging, training, and using matters.
Laser tube metal cutting machine double chuck for steel for sale in Italy samples
We provide free proofing service. Welcome to consult.
Laser tube metal cutting machine double chuck for steel for sale in Italy Cutting parameter map
Customer Reviews
Components of Fiber Laser tube Cutting machine
Intelligent focusing laser head
1) Cooling: both the collimating lens and the focusing lens group are cooling accessories. Besides, the cooling airflow nozzle is added, which effectively protects the nozzle and the ceramics and prolongs the working time.
2) Chasing aperture: through the 35 mm aperture, the interference of stray light is effectively reduced.
3) Autofocus: without human interference, the focusing speed can reach 10m/min, and the repeatability is about 50 microns.
Thick-walled carbon steel plate welding bed
Adopting high-quality carbon plate steel welding bed, it is more stable and durable than normal tube welding bed. The high-strength machine tool adopts 600 ℃ stress relief annealing treatment, which has strong structural rigidity, small deformation, and low vibration to ensure cutting accuracy.
Aviation aluminum beam
1) It has the characteristics of corrosion resistance, light weight, and high rigidity, which ensures high-speed movement during laser processing.
2) It has perfect dynamic performance, such as anti-distortion, anti-overturning, anti-deformation, etc., ensuring higher cutting accuracy.
Weihong LS1500/LS3000 Laser Cutting Control System
Weihong laser cutting control system is a software for plane laser cutting. It supports AI, DXF, PLT and international standard G codes generated by Mater Cam, Type3, Wentai, etc.
Except common editing and typesetting functions, it has unique processing sequence browsing and powerful material database to load the specification directly. Besides, operators can control the system through wireless handheld box and Ethernet conveniently.
